SMA Sunny Tripower Core2 110kW Inverter

SMA Sunny Tripower Core2 110kW inverter is the most suitable choice for large-scale industrial solar power projects. With a capacity of 110kW, 24 Strings and 12 MPPTs, Sunny Tripower Core2 is especially suitable for rooftop solar power systems with different slopes. The integrated SMA ShadeFix software solution automatically optimizes system performance even when the panels are shaded. The automatic monitoring service SMA Smart Connected will detect failures as quickly as possible to ensure maximum system output at all times…

Hotline: 1800 6567
Yêu cầu báo giá

Specifications

Capacity: 110 kW Maximum efficiency: 98.6%
Trademark: SMA Protection level: IP66
Display: LED indicator Communication standards: Ethernet
See detailed specifications
Model
Sunny Tripower Core2
Input (DC)
Maximum input power 165000 Wp STC
Maximum input voltage 1100 V
MPP voltage range/Rated input voltage 500 – 800 V
Rated input voltage 585 V
Min. input voltage/Startup input voltage 200 V / 250 V
Max. input current per MPP tracker / Max. short-circuit current per MPP tracker 26 A / 40 A
Number of independent MPP trackers / Strings per MPP tracker 12 / 2
Output (AC)
Rated capacity 110000 W
Max. apparent AC power 110000 VA
Nominal AC voltage 400 V
AC voltage range 320 V to 460 V
AC grid frequency / range 50 Hz / 45 Hz to 55 Hz 60 Hz / 55 Hz to 65 Hz
Rated power frequency/rated grid voltage 50Hz
Max. output current 159 A
Feed-in phases / AC connection 3 / 3-PE
Power factor at rated power / displacement power factor adjustable 1 / 0.8 leading to 0.8 lagging
THD < 3%
Efficiency
Max. efficiency/European efficiency 98.6% / 98.4%
Protective equipment
DC isolation equipment
Ground fault monitoring / Grid monitoring / DC reverse current protection ● / ● / ●
AC short-circuit current capability / galvanically isolated ● / —
Pole sensitive residual-current monitoring unit
Protection class (according to IEC 62109-1) / overvoltage category (according to IEC 62109-1) I / AC: III; DC: II
Surge arrester (type II) AC / DC ● / ●
General data
Dimensions (W x H x D) 1117 x 682 x 363 mm (44.0 x 26.9 x 14.3 in)
Weight 93.5 kgs (206.1 lbs)
Operating temperature range −30 °C to +60 °C (−22 °F to +140 °F)
Noise emission < 65 db(A)
Power consumption (night) < 5 W
Topology / cooling concept Transformerless / active cooling
Protection class (according to IEC 60529) IP66
Max. permissible value for relative humidity (non-condensing) 100%
Features
DC connection/AC connection Sunclix / terminal lug (up to 240 mm²)
Mounting
LED display (Status / Fault / Communication)
Ethernet interface ● (2 ports)
Data interface Web Interface / Modbus SunSpec
Mounting type wall mounting / rack mounting
Warranty: 5 / 10 / 15 / 20 years ● / ○ / ○ / ○
Certifications and approvals IEC 62109-1/-2, EN50549-1/-2:2018, VDE-AR-N 4105/4110/4120:2018, IEC 62116, IEC 61727, C10/C11 LV2/MV1:2018, CEI 0-16:2019, AS/NZS 4777.2, SI 4777, TOR Generator Type A/B
Note ● Standard features  ○ Optional features —  Not available
Product code STP 110-60

DAT SOLAR – AUTHORIZED DISTRIBUTOR OF SOLAR INVERTER SERIES OF SMA

With more than 400 experienced employees always ready to support 24/7 before and after sales, DAT Solar is committed to ensuring the quality of all products distributed nationwide and providing smart solutions to help customers save time and costs.

Another reason for you to rest assured to put your trust in us:

medal

15+

Year Of Experiences

400+

Staff
storage

9500+

Solar power system with a total
capacity of 560MW nationwide

10+

10MW inverter
are always available

ACCOMPANY DAT TO "GREEN" VIETNAM WITH SOLAR POWER YOUR WAY!

OUTSTANDING FEATURES

More flexibility

  •  For large rooftop and ground-mounted systems up to the MW range
  • 12 MPP trackers
  • 24 strings with 1100 VDC Sunclix connector

More power

  • 110 kW for standard 400 VAC
  • Fast commissioning without
  • additional DC combiners
  • Peak efficiency of 98.6%

More yield

  • Premium monitoring service for reliable system performance
  • Maximum yields thanks to the integrated software solution SMA ShadeFix

More system integration

  • Flexible and future-proof expansion in the SMA Energy System Business
  • Holistic energy management with ennexOS
  • High security

POLICY

Warranty: 5 years (standard) / 10, 15, 20 years (optional)
