SMA Sunny Tripower 25kW Inverter

The 25kW Sunny Tripower Inverter series, manufactured by the world’s leading brand SMA (Germany), is the perfect inverter for large-scale, enterprise solar power systems. The product has a high conversion efficiency of up to 98.3% and a flexible design, compatible with many PV modules thanks to its multiphase capability and wide input voltage range.

Hotline: 1800 6567
Yêu cầu báo giá

Specifications

Capacity: 25 kW Maximum efficiency: 98.3%
Trademark: SMA Protection level: IP65
Display: LCD display (Optional) Communication standards: RS485, Speedwire (Optional)/Webconnect
See detailed specifications
Sunny Tripower 25000TL
Đầu vào (DC)
Max. generator power
45000Wp
DC rated power
25550W
Max. input voltage
1000V
MPP voltage range / rated input voltage
390V to 800V/600V
Min. input voltage / start input voltage
150V/188V
Max. input current input A / input B
33A/33A
Number of independent MPP inputs / strings per MPP input
2/A:3;B:3
Output (AC)
Rated power (at 230 V, 50 Hz)
25000W
Max. AC apparent power
25000VA
AC nominal voltage
3/N/PE; 220V/380V 3/N/PE; 230V/400V 3/N/PE; 240V/415V
AC voltage range
180V to 280V
Rated power frequency / rated grid voltage
50Hz/230V
Max. output current / Rated output current
36.2A/36.2A
Power factor at rated power / Adjustable displacement power factor
1/0 overexcited to 0 underexcited
THD
≤ 3%
Feed-in phases / connection phases
3/3
Effi ciency
Max. efficiency / European Efficiency
98.3%/98.1%
Protective devices
DC-side disconnection device
Ground fault monitoring / grid monitoring
● / ●
Ground fault monitoring / grid monitoring
DC reverse polarity protection / AC short-circuit current capability / galvanically isolated
● / ● / —
All-pole sensitive residual-current monitoring unit
Protection class (according to IEC 62109-1) / overvoltage category (according to IEC 62109-1)
I / AC: III; DC: II
General data
Dimensions (W/H/D)
661/682/264 mm (26.0/26.9/10.4 inches)
Weight
61kg (134.48lb)
Operating temperature range
-25°C to +60°C (-13°F to +140°F)
Noise emission (typical)
51dB(A)
Self-consumption (at night)
1W
Topology / cooling concept
Transformerless/Opticool
Degree of protection (as per IEC 60529)
IP65
Climatic category (according to IEC 60721-3-4)
4K4H
Maximum permissible value for relative humidity (non-condensing)
100%
Characteristics
DC connection / AC connection
SUNCLIX / spring-cage termina
Display
Interface: RS485, Speedwire/Webconnect
○ / ●
Data interface: SMA Modbus/SunSpec Modbus
● / ●
Multifunction relay / Power Control Module
○ / ○
OptiTrac Global Peak / Integrated Plant Control / Q on Demand 24/7
● / ● / ●
Off-Grid capable / SMA Fuel Save Controller compatible
● / ●
Guarantee: 5/10/15/20 years
● / ○ / ○ / ○
Ability to operate independently of the grid/Compatible with SMA fuel economy controller.
● / ●
Certificates and permits (more available on request) * Does not apply to all national appendices of EN 50438
ANRE 30, AS 4777, BDEW 2008, C10/11:2012, CE, CEI 0-16, CEI 0-21, EN 50438:2013*, G59/3, IEC 60068-2-x, IEC 61727, IEC 62109-1/2, IEC 62116, NBR 16149, NEN EN 50438, NRS 097-2-1, PPC, RD 1699/413, RD 661/2007, Res. n°7:2013, SI4777, TOR D4, TR 3.2.2, UTE C15-712-1, VDE 0126-1-1, VDE-AR-N 4105, VFR 2014
Note
● Basic function ○ Optional function — No support
Type designation
STP 25000TL-30

DAT SOLAR – AUTHORIZED DISTRIBUTOR OF SOLAR INVERTER SERIES OF SMA

With more than 400 experienced employees always ready to support 24/7 before and after sales, DAT Solar is committed to ensuring the quality of all products distributed nationwide and providing smart solutions to help customers save time and costs.

Another reason for you to rest assured to put your trust in us:

medal

15+

Year Of Experiences

400+

Staff
storage

9500+

Solar power system with a total
capacity of 560MW nationwide

10+

10MW inverter
are always available

ACCOMPANY DAT TO "GREEN" VIETNAM WITH SOLAR POWER YOUR WAY!

OUTSTANDING FEATURES

Safety: Can integrate DC surge protection (Type II SPD).

Flexible

  • Input DC voltage up to 1000V.
  • Multiple input branches for design flexibility.
  • LCD display can be integrated.

New improvements

  • Modern grid management function integrated system control.
  • Can provide 24/7 Q power.

POLICY

Warranty: 5 years (standard) / 10, 15, 20 years (optional)
